Yilmaz, S.; Choi, J.; Uguz, I.; Kim, J.; Akrouh, A.; Taal, A. J.; Andino-Pavlovsky, V.; Yin, H.; Fabbri, J. D.; Moreaux, L.; Roukes, M. L.; Shepard, K. L.

Despite the advantages of optical imaging over electrophysiology, such as cell-type specificity, its application has been limited to the investigation of shallow brain regions (< 2 mm) because of the light scattering property of brain tissue. Passive optical conduits such as graded-index lenses and waveguides have permitted access to deeper locales but with restricted resolution and field of view, while creating massive lesions along the inserted path, with little pathway to improvement in the technology. As an alternative, we present the Acus device, an active implantable complementary metal-oxide-semiconductor (CMOS) neural imager with a 512-pixel silicon image sensor post-processed into a 4.1-mm-long, 120-m-wide shank with a collinear fiber for illumination, which is able to record transient fluorescent signals in deep brain regions at 400 frames/sec. Acus can achieve single-neuron resolution in functional imaging of GCaMP6s-expressing neurons at a frame rate of 400 frames/sec.
