Park, J.; Rahematpura, A.; Beresin, E.; Majumdar, A.; Azeem, Y.; Mizukai, H.; Ghanim, R.; Jackson, J.; Healy, S.; Ding, J. Z.; Clinch, M.; Abbas, A. M.; Belanger, M.; Dahlman, J. E.; Chan, J. L.; Abramson, A.

Angiogenesis-promoting macromolecules reduce adverse remodeling and preserve cardiac function in rodents following myocardial infarctions, yet repeatedly fail to translate across length scales in humans. Through mass transport studies in human and swine myocardium, we found that dense, anisotropic myocardial fibers limit therapeutic diffusion and convection to millimeter scales for existing approaches including bolus intramyocardial injections, shear-thinning hydrogels, and epicardial patches. Furthermore, distributions are confined to one dimension along fibers. To increase myocardial drug distribution to centimeter length scales in vivo in swine, we engineered a three-dimensional multi-injection drug delivery array. Our device performs up to 40 simultaneous 120 L injections of functional macromolecules, hydrogels, or mRNA lipid nanoparticles. Injections are precisely placed in relation to fiber alignment, achieving near-complete coverage of the left ventricular myocardium.
