Umney, O.; Curd, A. P.; Martin, H.; Lewis, T.; Tang, A. A.-S.; Balusubramanian, H.; Khuon, S.; Aaron, J.; Peckham, M.

Sarcomeres, the basic repeating unit of striated muscle, are joined together by crosslinked actin filaments found at the boundaries of muscle sarcomeres, termed Z-discs. Z-discs play a key role in cardiac signalling and disease, however, the arrangement and function of many of the proteins present in the Z-disc remain to be understood. Here, we determined the organisation of 3 key proteins, ZASP, -Actinin-2 and the Z1Z2 epitope of titin, located within the Z-disc. We fluorescently labelled these proteins in cardiac myofibrils using Adhirons specific to each protein and used interferometric photoactivated localization microscopy (iPALM) to obtain the 3D position of these proteins to a high precision (<10nm in x,y,z). We then used PERPL (Pattern Extraction from Relative Positions of Localisations) to analyse patterns in the relative positions of the proteins and reveal their underlying organisation. This analysis revealed that ZASP and -Actinin-2 have a similar repeating organisation, but that the organisation of Z1Z2 is different.
